144 Cavity PET Preform Mould | Ideal Choice for High-Efficiency Continuous Production

Optimized 144-cavity layout for maximum output：Engineered with a high-density 8×18 cavity configuration, enabling continuous mass production while maintaining stable cycle consistency and balanced filling across all cavities.

Stable molding performance under high-speed operation: Designed for long-term, high-speed injection cycles with consistent repeatability, ensuring uniform preform dimensions, precise neck accuracy, and stable molding quality shot after shot.

Advanced Engineering: Features a balanced hot runner system with pneumatic needle point valves, ensuring zero gate waste and superior surface finish.

Standardized Dimensions: Optimized for international standard machine platens, SZ-MOLDTECH selects premium tool steel from world-renowned suppliers including UDDEHOLM, Bosch Gotthards Huette, and Schmiede Werke Groditz GmbH for core and cavity components, combined with advanced machining and surface treatment technologies to ensure exceptional durability, stable molding performance, and a service life exceeding 8 million cycles.

MOULD PITCH LAYOUT

CAVITATION	LAYOUT	PITCH	Thread up to	Support ring up to	MAX.body Dia.
48CAV.	4X12	60X152	38mm	42mm	38mm
72CAV.	6X12	60X140	38mm	42mm	38mm
	6X12	50X140(2X100)	30mm	34mm	30mm
	6X12	50X120(1X120)	30mm	34mm	30mm
96CAV.	8X12	60X140	38mm	42mm	38mm
	6X16	50X140(2X100)	30mm	34mm	30mm
	8X12	50X120(1X100)	30mm	34mm	30mm
	6X16	60X114(1X120)	38mm	42mm	38mm
128CAV.	8X16	50X120(1X100)	30mm	34mm	30mm
128CAV.	8X16	50X111	30mm	34mm	30mm
144CAV.	8X18	50X140(3X100)	30mm	34mm	30mm

The mould is applicable to various machine models, subject to confirmation by the project engineer.

144 Cavity PET Preform Mold
The 144-cavity PET preform mold is constructed with high-precision steel and features a stable cooling system, ensuring simultaneous molding of multiple cavities and consistently high production
144 Cavity Hot Runner PET Preform Mould For Water Bottles
144 Cavities: Produces 144 PET preforms per shot, suitable for high-volume water bottle production.Hot Runner System: Optimized melt flow and balanced filling help maintain consistent preform weight
Cold Runner Preform Plastic Injection Mould
This cold‑runner PET preform injection mold adopts a cold‑runner structure for production. Its precision‑machined cavities and cores guarantee uniform preform wall thickness and dimensional
144 Cavity PET Injection Mould
144 Cavity PET Injection Mould is designed for high-volume PET preform production, offering stable performance, precise cavity control, and efficient injection cycles. The mould adopts optimized flow

First 12 3 4 5 6 7 Last

Advanced 144 Cavity PET Preform Mould for High-Speed PET Bottle Manufacturing

SZ-MOLDTECH specializes in the design and manufacturing of high-precision 144 cavity PET preform moulds for large-scale PET bottle production. With advanced European mould manufacturing concepts and years of experience in PET packaging applications, we provide reliable and cost-effective mould solutions for global beverage, food packaging, and consumer product manufacturers.

Our 144 cavity PET preform moulds are developed for high-output production environments where mould precision, stability, and long-term performance are critical. Each mould is customized according to specific requirements, including preform weight, neck finish, bottle design, filling method, and production capacity.

From mould design, precision machining, component inspection, assembly, and trial production to final delivery, every step is strictly controlled. Before shipment, each mould undergoes complete testing to ensure customers can install it directly on their injection molding machines and start production with confidence.

Request Your Solution Explore Technology

144 Cavity PET Preform Mould

Precision Engineered 144 Cavity PET Preform Mould

A high cavity PET preform mould requires excellent structural design and manufacturing accuracy to achieve stable production performance. The consistency of each cavity directly affects preform quality, production efficiency, and the operating cost of the entire production line.

At SZ-MOLDTECH, we focus on every manufacturing detail and control each process carefully to ensure reliable mould performance.

144

Cavity High Output

European

Technology Concept

100%

Component Inspection Tested

Optimized Mould Design & Stable Production Performance

Optimized Mould Design

Professional 3D design and engineering analysis are applied during mould development.

The mould structure is optimized according to preform weight, neck finish, bottle application, and injection requirements.

Balanced cavity layout ensures uniform material distribution and stable injection performance.

Cooling system design is optimized to improve cycle efficiency and maintain consistent mould temperature.

Stable High-Speed Production

Precision machining ensures accurate cavity dimensions and reliable long-term operation.

High-quality components improve mould durability under continuous production conditions.

Optimized design helps reduce production adjustments and improves overall manufacturing efficiency.

Reliable Hot Runner Performance

The hot runner system is designed to achieve balanced melt distribution across all cavities.

Precise temperature control helps maintain consistent preform quality.

The solution is suitable for high-volume PET bottle production in beverage and food packaging industries.

144 Cavity PET Preform Mould Applications

Beverage Packaging Applications

Designed for various beverage bottle production requirements, including:

✓ Mineral water bottles
✓ Carbonated beverage bottles
✓ Juice bottles
✓ Functional drink bottles

Food Packaging Applications

Suitable for PET containers used in:

✓ Edible oil bottles
✓ Food-grade PET packaging
✓ Consumer product containers

High-Volume PET Production

Ideal for:

✓ Large-scale PET bottle manufacturers
✓ Automated injection molding production lines
✓ Continuous high-output production

Our 144 cavity PET preform moulds combine precision manufacturing and stable operation to support efficient mass production with consistent preform quality.

Customized Solutions for Different PET Injection Machines

A PET preform mould needs to be precisely matched with the injection molding machine to ensure stable operation and consistent preform quality. SZ-MOLDTECH develops customized mould solutions according to machine specifications, production requirements, and application conditions.

Husky

Netstal

Huayan

Compatible with various PET injection molding machines based on customer specifications and production requirements.

Customized Solutions for Different PET Injection Machines

Professional Engineering Evaluation

01

Injection Machine Compatibility Analysis

02

Preform Structure Assessment

03

Production Capacity Planning

04

Bottle Application Evaluation

Before starting each PET preform mould project, our engineering team conducts a detailed technical evaluation to ensure the mould design matches the customer's production requirements and operating conditions.

Professional PET Preform Mould Manufacturing Capability

SZ-MOLDTECH specializes in providing precision PET preform mould solutions for global beverage and food packaging manufacturers. By integrating European mould manufacturing concepts with efficient production capabilities, we deliver mould solutions that combine high precision, stable performance, and competitive cost advantages.From mould design and component processing to assembly and testing, every manufacturing stage is carefully controlled to ensure each mould meets the requirements of high-speed PET production.

Advanced Manufacturing Equipment

Our manufacturing capability is supported by advanced precision processing equipment, including:

CNC machining centers
EDM processing equipment
Precision grinding machines
Coordinate measuring equipment

These facilities enable accurate component machining, strict dimensional control, and consistent mould performance during long-term production.

Experienced Engineering Team

Our engineering team has extensive experience in PET preform mould development and focuses on optimizing the relationship between:

Bottle design requirements
Preform structure design
Injection molding parameters
Mould performance

Through professional engineering analysis and practical production experience, we provide customized mould solutions that help customers improve production efficiency and achieve stable PET preform quality.

Strict Quality Control From Design to Delivery

Inspection During Manufacturing

For a 144 cavity PET preform mould, quality cannot rely only on final inspection. SZ-MOLDTECH applies strict quality control throughout the entire manufacturing process.

✓ Component dimensions

✓ Machining accuracy

✓ Surface quality

✓ Assembly precision

Complete Trial Production Before Shipment

After mould assembly, every mould must complete trial production before delivery.

During testing, we inspect cavity operation, preform weight consistency, product appearance, injection stability and cooling performance.

Production-Ready Delivery

Our goal is to provide customers with a mould that can be used directly after installation.

Through complete testing before shipment, customers can reduce adjustment time and start production more efficiently.

Safe Packaging & Global Delivery Service

PET preform moulds are precision products that require professional protection during transportation. SZ-MOLDTECH provides reliable packaging and international delivery services to ensure mould safety.

✓ Anti-rust treatment

✓ Moisture protection

✓ Protective wrapping

✓ Customized wooden case packaging

Why Choose SZ-MOLDTECH as Your 144 Cavity PET Preform Mould Supplier?

European Mould Technology Concept

We integrate European mould manufacturing concepts into our product development and production process, combining advanced design standards with efficient manufacturing methods to deliver reliable PET preform mould solutions.

Strict Manufacturing Process Control

Every mould is produced under a complete quality control process, covering component inspection, precision machining, mould assembly, trial production, and final verification to ensure stable performance and consistent quality.

Customized Engineering Solutions

We provide tailored PET preform mould solutions based on customer requirements, including bottle design, preform specifications, production capacity, and injection machine conditions to achieve optimal production performance.

Reliable Long-Term Partnership

We focus on building long-term cooperation with global customers through stable mould quality, professional technical communication, responsive service, and continuous production support.

Frequently Asked Questions About 144 Cavity PET Preform Mould

Learn more about mould design, production performance, customization process and technical support before starting your PET preform mould project.

How can you help us reduce production costs with a 144 cavity PET preform mould?

Can you develop a PET preform mould based on our existing bottle design?

What information do you need before starting a new PET preform mould project?

How do you ensure the mould can run smoothly after delivery?

What support can you provide after mould delivery?

Discuss Your PET Preform Mould Project

We are among the most professional manufacturers and suppliers of high-speed multi-cavity PET preform molds in China, offering comprehensive customized solutions. We welcome you to source high-quality, high-speed multi-cavity PET preform molds manufactured in China directly from our facility.The performance of SZ-MOLDTECH products is on par with that of their international counterparts. Compared to brands such as HUSKY and MHT, our molds maintain superior performance while providing a distinct cost-performance advantage.
